Toggle Clamp – CL-350-PA Series (1000 lbs)
CL-350-PALatch clamp with a versatile hook for grasping a rod or rim. Clamp latches horizontally, vertically, or at any angle in between. 6-1/8″ drawing movement. Threaded hook allows an 3/4″ adjustment range. Order matching latch plate separately. 1000 lbs holding capacity.
| Product Type | Toggle Clamp |
|---|---|
| Maximum Holding Capacity | 1000 lbf |
| Clamp Type | Latch |
| Draw Arm Style | Hook |
| Material | 1215 Steel;1008 Steel;1010 Steel;1018 steel (Plunger and Links);400 Stainless (Rivets);Vinyl (Handle) |
| Finish | Zinc Plated Clear Chromate |
| Mounting Type | Flanged |
| Handle Material | Vinyl |
| Standards Met | DFARS;RoHS Compliant |
