Toggle Clamp – CL-500-PA Series (7500 lbs)

Toggle Clamp – CL-500-PA Series (7500 lbs)

$365.05


Brand: Carr Lane

Toggle Clamp – CL-500-PA Series (7500 lbs)

SKU: CL-500-PA-S Category:

Description

CL-500-PAStrongest latch clamp available. Rugged alloy steel handle, base, and latch plate provide great strength in a compact overall size. Versatile latch clamp with a threaded U bolt for adjustability. 2-1/2″ drawing movement. Threaded U bolt allows a 15/16″ adjustment range. Available in in steel or stainless steel. Order matching latch plate separately. Optionally available with our safety-lock feature (see Related Products below). 7500 lbs holding capacity.

Additional information

Product Type

Toggle Clamp
Maximum Holding Capacity

7500 lbf
Clamp Type

Latch
Material

Alloy Steel (Handle, base, and latch plate);1215, 1008, 1010, and/or 1018 steel (U bolt and crosspin);400 Stainless (Rivets);300 Stainless (Handle, Base, Latch Plate, U Bolt, and Crosspin)
Finish

Zinc Plated Clear Chromate
Mounting Type

Flanged
Handle Material

Alloy Steel
Standards Met

DFARS;RoHS Compliant
