$39.16
Push/Pull Toggle Clamp – CL-60-SPC Series (150 lbs)
CL-60-SPC Tapped PlungerHeavier-duty version of our smallest plunger clamp (CL-50-SPC). This is a powerful clamp in an extremely compact size. Unique base allows bottom or side mounting. Locks in extended or retracted position. 5/8″ plunger travel. Plunger is tapped to accept any #8-32 spindle (M4 in metric). Available in in steel or stainless steel. 150 lbs holding capacity.
| Product Type | Push/Pull Toggle Clamp |
|---|---|
| Maximum Holding Capacity | 150 lb |
| Plunger Travel | 5/8 in |
| Plunger Thread | #8-32 |
| Material | 1215 Steel (Clamp Body);1008 Steel (Clamp Body);1010 Steel (Clamp Body);1018 Steel (Clamp Body);400 Stainless (Rivets);Vinyl (Handle);300 Stainless (Clamp Body) |
| Handle Material | Vinyl |
| Finish | Zinc Plated Clear Chromate |
| Mounting Type | Flanged |
| Thread Size | #8-32 |
| Standards Met | DFARS;RoHS Compliant |
