Push/Pull Toggle Clamp – CL-650-SPC Series (16000 lbs)
CL-650-SPCTapped PlungerStrongest plunger clamp available. Handle and base are made of alloy steel. Precision unit with snap ring pivot pins to allow removing the plunger even after the clamp is mounted. Locks in extended or retracted position. 3″ plunger travel. Plunger is tapped to accept any 5/8-11 spindle (M16 in metric). 16000 lbs holding capacity.
| Product Type | Push/Pull Toggle Clamp |
|---|---|
| Maximum Holding Capacity | 16000 lb |
| Plunger Travel | 3 in |
| Plunger Thread | 5/8 in – 11 |
| Material | Cast Alloy Steel (Handle and Bases);1215, 1008, 1010, and/or 1018 steel (Plunger and Links);400 Stainless (Rivets) |
| Handle Material | Cast Alloy Steel |
| Finish | Zinc Plated Clear Chromate |
| Mounting Type | Flanged |
| Thread Size | 5/8 in – 11 |
| Standards Met | DFARS;RoHS Compliant |
