Revolving Handle – Square Design, Threaded (Stainless Steel)

Revolving Handle – Square Design, Threaded (Stainless Steel)


Brand: Carr Lane

Revolving Handle – Square Design, Threaded (Stainless Steel)

SKU: CL-100-RH-S Categories: ,

Description

Modern square-design handle made of stainless steel, with a polished finish. Revolving Handles have an internal bearing that allows the handle to remain fixed in your hand, for firm gripping while turning a Hand Wheel or crank. Revolving handles are available in a total of five handle sizes. The square-design version shown here is available in the first four of the five sizes, with the following threads: Size 1 1/4-20 (M6 in metric) Size 2 1/4-20 (M6 in metric) Size 3 5/16-18 (M8 in metric) Size 4 3/8-16 (M10 in metric)

Additional information

Product Type

Revolving Handle

Thread Size

1/4 in – 20

Material

300 Stainless Steel

Handle Size

Size 1

Screw Length (B)

9/32 in

Body Diameter (D)

5/8 in

Body Length (A)

1-1/2 in

Standards Met

DFARS;RoHS Compliant

Dimension (Dia E)

15/32 in

Dimension (F)

5/16 in

Dimension (G)

0.2 in
