Round Gripper (Carbide Tipped, Serrated)

Round Gripper (Carbide Tipped, Serrated)

$33.92


Brand: Carr Lane

Round Gripper (Carbide Tipped, Serrated)

SKU: CL-12-RGT Category:

Description

Serrated Round Grippers are hard, replaceable inserts that provide additional holding force and/or wear resistance when installed in a fixture. These grippers are designed to slightly penetrate the workpiece to significantly increase gripping force, rather than relying on static friction alone. The carbide-tipped grippers shown here are economical and impact resistant while providing extra durability. Available in diameters from 3/8 to 1″ (10 to 25mm in metric). Made in USA.

Additional information

Product Type

Round Gripper

Thread Size

1/4 in – 28

Diameter

3/4 in

Hub Length

3/16 in

Material

Alloy Steel

Finish

Black Oxide

Thread Depth (D)

3/16 in

Serration Type

Fine

Serration Dimensions

0.125 in x 90°

Height (B)

3/8 in

Dimension (F)

11/64 in

Dimension (G)

5/8 in

Standards Met

DFARS;RoHS Compliant
