Solid Handle

Solid Handle

$33.70


Brand: Carr Lane

Solid Handle

SKU: CLM-400-RH-S Category:

Description

Modern square-design handle made of stainless steel, with a polished finish. Revolving Handles have an internal bearing that allows the handle to remain fixed in your hand, for firm gripping while turning a Hand Wheel or crank. Revolving handles are available in a total of five handle sizes. The square-design version shown here is available in the first four of the five sizes, with the following threads: Size 1 1/4-20 (M6 in metric) Size 2 1/4-20 (M6 in metric) Size 3 5/16-18 (M8 in metric) Size 4 3/8-16 (M10 in metric)

Additional information

Product Type

Solid Handle

Thread Size (C)

M10

Material

300-Series Stainless Steel

Handle Size

Size 4

Screw Length (B)

16 mm

Thread Pitch

1.5 mm

Body Diameter (D)

22 mm

Body Length (A)

83 mm

Standards Met

DFARS;RoHS Compliant

Dimension (Dia E)

16 mm

Dimension (F)

11 mm

Dimension (G)

8 mm
