Toggle Clamp – CL-650-VTC Series (750 lbs)

Toggle Clamp – CL-650-VTC Series (750 lbs)


Brand: Carr Lane

Toggle Clamp – CL-650-VTC Series (750 lbs)

SKU: CL-650-VTC-S Category:

Description

CL-650-VTC Open Arm, Flanged Base Large wide-opening clamp, available in several configurations. Arm opens 106° while handle moves 58°. Choose either an open arm for adjustable spindle location, or a solid arm for fixed spindle location. Choice of flanged base or straight base. Available in in steel or stainless steel. Optionally available with our safety-lock feature, and in an automatically adjusting version (see Related Products below). 750 lbs holding capacity.

Additional information

Product Type

Toggle Clamp

Maximum Holding Capacity

750 lb

Material

1008 Steel;1010 Steel;1018 Steel (Clamp Body);400 Stainless (Rivets);Vinyl (Handle);300 Stainless (Clamp Body)

Base Mounting Style

Flanged

Clamp Arm Style

Open Arm

Handle Style

Vertical

Standards Met

DFARS;RoHS Compliant
